Pewag Winner Inox G6+ Four Leg Chain Sling Assembly
PEW-CS-G6-4L
Pewag Winner Inox G6+ four leg stainless steel welded chain sling for hygienic and corrosive environments. Fully welded with 100% penetration for contamination-free lifting. Ideal for large or complex loads in food, chemical, water, marine and clean technology industries. Manufactured to order.
From: £914.59£1,097.51 From: £823.13£987.76 Exc VATInc VAT
Description
Pewag Winner Inox G6+ Four Leg Chain Sling Assembly – 1.89t-13.2t WLL
The Pewag Winner Inox G6+ Four Leg Stainless Steel Welded Chain Sling is a premium lifting solution designed for large, complex and multi-point loads where hygiene, corrosion resistance and operational safety are essential. Manufactured from high-quality stainless steel, the sling is fully welded using advanced butt resistance or flash butt welding techniques to provide 100% weld penetration throughout the chain and connecting components.
The fully welded construction eliminates cavities, cracks and voids where water, chemicals or residue could collect, making the Winner Inox G6+ particularly suitable for hygienic environments and aggressive industrial applications. The smooth stainless steel finish also allows the sling to be cleaned and sanitised efficiently.
The four-leg configuration is particularly suited to box-shaped loads, frames and large fabrications with multiple lifting points, providing improved stability and load control during lifting. In standard lifting configurations, only two legs are considered load-bearing, while the additional legs assist with stabilising and correctly positioning the load.
The welded stainless steel construction is well suited to applications involving vibration and repetitive lifting, while the corrosion-resistant material allows the sling to be used across a wide range of indoor and outdoor environments.
Winner Inox G6+ Stainless Steel Chain for Hygienic & Corrosive Environments
Pewag Winner Inox G6+ chain is manufactured from high-quality stainless steel to provide corrosion resistance, durability and a smooth surface that is easy to clean and sanitise.
The stainless steel construction makes the sling suitable for environments where hygiene, cleanliness or resistance to corrosive substances are important considerations.
Winner Inox G6+ chain slings replace the outgoing Grade 50 programme, providing an updated stainless steel lifting solution for specialist industrial and hygienic applications.
Fully Welded Construction
Winner Inox G6+ chain is manufactured using advanced butt resistance or flash butt welding techniques, producing 100% full penetration welds.
The welded construction eliminates cavities, cracks and voids around the welded areas, helping to reduce potential locations where water, chemicals or other residues can accumulate.
The construction is also well suited to applications involving vibration, providing a durable solution for repetitive and demanding lifting operations.
Four Leg Configuration for Large & Complex Loads
The four-leg configuration is designed for loads with multiple lifting points and is particularly useful for box-shaped loads, frames, fabricated structures and other large assemblies.
In standard lifting configurations, only two legs are considered load-bearing, with the additional legs helping to stabilise and position the load during lifting.
Correct sling angles and load distribution must always be considered when selecting and using a four-leg sling. The Working Load Limit depends on the specific configuration and angle of inclination.
Flexible Assembly & Connection Options
The Pewag Winner Inox G6+ Four Leg Chain Sling can be configured with a range of connection arrangements to suit different lifting applications, including:
- Sling hooks with latch
- Endless loops
- Single captive basket slings
- Double captive basket slings
- U-shaped assemblies with master links
Each sling is manufactured to the required effective working length, allowing the assembly to be configured to suit the intended lifting arrangement.
Ideal Applications
Pewag Winner Inox G6+ Four Leg Chain Slings are particularly suited to specialist lifting applications including:
- Food processing
- Slaughterhouses
- Fishing industry
- Chemical processing
- Oil processing
- Water and wastewater treatment
- Pump industries
- Clean technology
- Renewable energy installations
- Marine and offshore environments
- Military applications
- Power plants
- Surface treatment facilities
- High-temperature environments
- Large frames and fabrications
- Box-shaped and multi-point loads
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Four Leg Stainless Steel Welded Chain Sling |
| Chain Type | Pewag Winner Inox G6+ |
| Configuration | Four leg |
| WLL Range | 1.89t–13.2t |
| Construction | Fully welded |
| Welding Process | Butt resistance or flash butt welding |
| Weld Penetration | 100% |
| Material | High-quality stainless steel |
| Connection Options | Sling hooks with latch, endless loops, captive basket slings and U-shaped assemblies |
| Master Link Options | Available with U-shaped assemblies |
| Effective Working Length | Manufactured to required length |
| Manufacture | Made to order |
| Documentation | Declaration of Conformity and safe use instructions |
Capacity & Load Information
The Working Load Limit of a four-leg chain sling depends on the specific sling configuration and angle of inclination.
Under standard lifting conditions, only two legs are considered load-bearing, with the additional legs providing stability and positioning. The load must therefore be assessed based on the applicable lifting configuration rather than assuming that the load is shared equally across all four legs.
Always observe the correct sling angle and ensure the selected sling is suitable for the intended lifting arrangement.
Additional reduction factors may apply in severe conditions, including edge loading, shock loading and vibration.
When wrapping the chain around a load or support, small diameter contact points can reduce the permissible Working Load Limit and must be taken into account.
The stated WLL range for this product is 1.89t-13.2t, subject to the selected configuration and applicable load conditions.
For applications involving high temperatures, specialist advice should be obtained before using the sling above 350°C.
Always refer to the relevant Pewag load charts and product documentation when selecting the correct sling.
Request a Pewag Winner Inox G6+ Four Leg Chain Sling
Pewag Winner Inox G6+ Four Leg Chain Slings are manufactured to order and can be configured with the required effective working length and connection arrangement.
For help selecting the correct stainless steel chain sling for your application, contact Lifting Gear Products with your required Working Load Limit, lifting arrangement and effective length.
Technical information
| Weight | N/A |
|---|---|
| WLL | 1.89t, 2.63t, 3.36t, 5.25t, 8.93t, 13.2t |
| Gauge | 6, 7, 8, 10, 13, 16 |
| Termination | Sling Hook, Shackle |
| Grade | 6 |
| Product Type | Chain Sling |
| Number of Legs | 4 |
Key Features
- Four-leg stainless steel welded chain sling
- Pewag Winner Inox G6+ chain
- 1.89t-13.2t WLL range
- High-quality stainless steel construction
- Fully welded chain
- Butt resistance or flash butt welding
- 100% full penetration welds
- No cavities, cracks or voids around the welded areas
- Excellent corrosion resistance
- Smooth, hygienic and easy-to-clean surface
- Suitable for applications involving vibration
- Designed for large, complex and multi-point loads
- Suitable for box-shaped loads, frames and large fabrications
- Choice of sling hooks, endless loops and captive basket configurations
- U-shaped assemblies with master links available
- Manufactured to the required effective working length
- Manufactured to order
- Supplied with Declaration of Conformity and safe use instructions
Safety & User Instructions
- Ensure all four legs are correctly attached before lifting.
- Only two legs are considered load-bearing under standard lifting conditions.
- Do not assume the load is shared equally between all four legs.
- Always confirm the Working Load Limit before lifting.
- Observe the correct sling angle and lifting configuration.
- Do not exceed the rated Working Load Limit.
- Ensure the load is properly balanced and securely attached.
- Apply the appropriate reduction factors for edge loading, shock loading and vibration.
- Take particular care when wrapping the chain around small diameter loads or supports.
- Do not use above 350°C without specialist advice.
- Inspect the chain, welds, hooks, links and other fittings before every lift.
- Remove the sling from service if any component shows signs of damage, deformation, cracking or excessive wear.
- Avoid shock loading and sudden movements during lifting.
- Ensure all master links and connecting components are correctly positioned and secured.
- Follow all supplied Pewag Winner Inox G6+ operating and safety instructions.
- Lifting operations should only be carried out by suitably trained and competent personnel.
