EcoWarrior Manually Operated Mobile Lift Table – 150kg-1t WLL
WAR-HE-MLT-WR
EcoWarrior Manual Mobile Lift Table range with 150kg-1,000kg WLL, foot-operated hydraulic lifting and mobile scissor designs.
From: £287.00£344.40 Exc VATInc VAT
Description
EcoWarrior Manually Operated Mobile Lift Table
The EcoWarrior Manual Mobile Lift Table range provides a practical and reliable solution for lifting, positioning and transporting loads in warehouses, workshops, production areas and industrial environments.
Available with Working Load Limits from 150kg to 1,000kg, the range includes compact single-scissor models for lighter handling applications through to larger and double-scissor configurations for heavier or higher lifting requirements.
Each lift table combines manual hydraulic lifting with a foot-operated pump, allowing operators to raise loads to a convenient working height while reducing the physical strain associated with manual handling. The mobile design, with two fixed wheels and two swivel castors, also allows the tables to be manoeuvred into position before and after lifting.
Manual Hydraulic Lifting
The EcoWarrior Mobile Lift Tables use a foot-operated hydraulic pump to raise the platform, providing controlled and progressive lifting without requiring an external power supply.
An infinitely controlled lowering mechanism allows the operator to lower the platform in a controlled manner, while high-quality hydraulics provide a positive feel during operation.
Depending on the selected model, maximum platform heights range from 720mm to 1,500mm, providing options for applications requiring either a convenient working surface or greater lifting height.
Mobile & Manoeuvrable Design
Each model is designed for mobile use and incorporates two fixed wheels and two swivel castors, with braking and foot guards to provide additional control and protection during loading and unloading.
The high pushing handle provides a convenient point for manoeuvring the table, while the compact construction of the smaller models makes them suitable for use where available floor space is limited.
Single & Double Scissor Options
The range includes both single-scissor and double-scissor configurations.
Single-scissor models provide a compact solution for general lifting and positioning applications, while the double-scissor models provide increased lifting heights on selected higher-capacity tables.
The range therefore offers a choice of configurations to suit different load capacities, platform sizes and required working heights.
Ideal Applications
Suitable for a wide range of manual handling and lifting applications, including:
- Warehouses and distribution centres
- Workshops
- Manufacturing and production areas
- Industrial facilities
- Maintenance operations
- Assembly areas
- Material positioning
- Workbench loading
- Stock handling
- General goods handling
- Production line operations
Technical Specifications
| Model | Capacity | Lowered Table Height | Raised Table Height | Table Dimensions (W x L) | Handle Height | Wheel Diameter | Strokes to Full Height | Scissor Type | Net Weight |
| WR15 | 150kg | 220mm | 720mm | 450 x 700mm | 950mm | 100mm | 28 | Single | 46kg |
| WR30 | 300kg | 285mm | 880mm | 500 x 850mm | 990mm | 125mm | 27 | Single | 74kg |
| WR50 | 500kg | 285mm | 880mm | 500 x 850mm | 990mm | 125mm | 27 | Single | 81kg |
| WR50L | 500kg | 290mm | 915mm | 810 x 1,600mm | 975mm | 125mm | 55 | Single | 154kg |
| WR75 | 750kg | 420mm | 990mm | 510 x 1,000mm | 990mm | 147mm | 45 | Single | 125kg |
| WR100 | 1,000kg | 380mm | 990mm | 510 x 1,016mm | 990mm | 147mm | 82 | Single | 140kg |
| WR100L | 1,000kg | 360mm | 1,360mm | 750 x 2,035mm | 1,000mm | 180/80mm | 200 | Single | 198kg |
| WR35D | 350kg | 335mm | 1,300mm | 500 x 910mm | 975mm | 125mm | 53 | Double | 105kg |
| WR70D | 700kg | 445mm | 1,500mm | 610 x 1,220mm | 1,015mm | 125mm | 97 | Double | 195kg |
Capacity & Load Information
The EcoWarrior Manual Mobile Lift Table range is available with capacities from 150kg to 1,000kg, depending on the selected model.
Always ensure the total load placed on the table does not exceed the Working Load Limit of the selected model. Loads should be positioned centrally and distributed as evenly as practical across the platform.
The larger WR100L model provides a 1,000kg capacity with a substantially larger 750 x 2,035mm platform and a maximum raised height of 1,360mm, making it suitable for applications requiring a larger working surface and increased lifting height.
The double-scissor WR35D and WR70D models provide increased maximum lifting heights of 1,300mm and 1,500mm respectively.
Technical information
| Weight | N/A |
|---|---|
| Product Type | Lift Table |
| WLL | 1t, 150kg, 300kg, 350kg, 500kg, 700kg, 750kg |
| Lift Height | 1300mm, 1360mm, 1500mm, 720mm, 880mm, 915mm, 990mm |
| Table Size | 450 x 700mm, 500 x 850mm, 810 x 1600mm, 510 x 1000mm, 510 x 1016mm, 750 x 2035mm, 500 x 910mm, 610 x 1220mm |
Key Features
- Working Load Limits from 150kg to 1,000kg
- Manual hydraulic operation
- Foot-operated lifting pump
- Infinitely controlled lowering mechanism
- High-quality hydraulics with a positive feel
- High pushing handle
- Two fixed wheels and two swivel castors
- Castors fitted with brakes and foot guards
- Single and double-scissor models available
- Compact and manoeuvrable design
- Multiple platform sizes available
- Suitable for lifting and positioning loads
- Suitable for use without an external power supply
Safety & User Instructions
- Never exceed the Working Load Limit of the selected model.
- Ensure the load is suitable for the table’s rated capacity and platform dimensions.
- Position loads centrally and distributes them evenly across the platform wherever possible.
- Ensure the table is positioned on a suitable, stable and reasonably level surface before lifting.
- Engage the wheel brakes before loading, unloading or raising the table.
- Do not move the table while a load is raised unless the manufacturer specifically permits this.
- Keep personnel clear of the table and load while raising and lowering.
- Do not allow personnel to stand beneath the raised platform.
- Do not use the lift table to raise or transport people.
- Take care around the scissor mechanism and other moving components due to potential pinch points.
- Keep hands, feet and other body parts clear of the scissor mechanism during operation.
- Ensure the load remains stable throughout lifting and lowering.
- Do not leave a raised load unattended.
- Inspect the platform, frame, wheels, castors, hydraulic system, pump and lowering mechanism before use.
- Check for hydraulic leaks, damaged components or excessive wear before operation.
- Do not use damaged or defective equipment.
- Ensure the wheel brakes and castor foot guards are functioning correctly.
- Only trained and competent personnel should operate the equipment.
- Follow the manufacturer’s operating instructions and applicable workplace safety requirements.
